smartPanel Mount and Power Supply Package for Apple iPad Air 4th/5th Gen (2020) & All iPad Pro 11 (USB-C only)

smartPanel Mount Package for Apple iPad Air 4th Gen or iPad Pro 11.

Includes Panel Mount, 150-301 2.7 Amp Power Supply, Fan Blower, USB-C cable

• Fits iPad Models:
• iPad Air 4th Gen (A2072, A2324, A2325, A2902, A2903, A2588, A2589, A2316)
• iPad Pro 11 (A1980, A2013, A1934, A2836, A2837, A2759, A2761, A2435, A2377, A2459, A2301, A2228, A2068, A2230)
• Full Package Includes:
• smartPanel Mount for iPad Air 4th Gen (25-39)
• smartPower 150-301 2.7 amp Dual Power Supply (Powers Mount Only)
• 14 or 28V fan blower power supply
• USB-C Cable with Open Wire Termination
• D-Sub 15-pin Solder Connector
• D-Sub Cable Shield

The smartPanel Mount Package for Apple iPad Air
4/5 Gen or iPad Pro 11 is a flush mounting system to easily dock and seamlessly integrate your existing iPad Air 4/5 Gen or iPad Pro 11 into your aircraft instrument panel, giving it a clean, professional appearance in an easy to view position! Once installed, the smartPanel mount allows your iPad to be docked in seconds, fully connected to the included 2.7 amp power supply and audio with built-in
cable ports. Removal is just as easy -- just slide, push, and remove!

If you were to buy all the components in this package on their own, you would spend $499 -- at $449, this money-saving package includes everything you will need to install and integrate the iPad Pro 11-in with your aircraft -
panel mount, 2.7 amp power supply, fan blower, and power and audio cables included.

Compatible with all models of iPad Air 4/5 Gen or
iPad Pro 11 size, the smartPanel Mount allows you to transform your new or existing panel and use the most recommended iPad size for aviation in the cockpit, fully integrated with your instrument panel. Your charts and approach plates are in easy sight for reference and you can even use your iPad Air 4/5 Gen as a multi-function display with the many popular iOS aviation apps available.

Power supplies may be installed as a minor alteration. Please refer to this link for the Guardian Avionics NORSEE Letter of Authorization.

Designed for General Aviation in mind.

The smartPanel Mount for iPad Air 4/5 Gen or iPad
Pro 11 was designed by aerospace engineers to perform in the unique environment of the cockpit. The spring actuated mounting cradle securely holds the iPad in place during the roughest of turbulence. The clean, flush mount has a shallow chassis allowing it to be easily installed in
even the smallest of instrument panels. Built-in port for the included USB-C  the package will keep cable safely and securely positioned behind the panel, allowing you the ability to connect to power, data, and audio without the cord mess. The included smartPower 150-301 power supply will convert any aircraft power from 9 to 48 volts down to the 5
volt, 2.7 amp power needed to power and charge your iPad Air 4th Gen or iPad Pro 11

Packaged with smartPower 150-301 Power Supply

The smartPanel Mount Package for iPad Air 4/5 Gen
or iPad Pro 11 includes the Power 150-301 Single USB Power Supply to provide power to the mount and your iPad Air 4/5 Gen! The smartPower 150-301 is a remote mounted Single USB type power / charging unit designed to mount directly on the included mounting positions on the
back of the iPad Air 4/5 Gen or iPad Pro 11. The smartPower 150-301 provides 2.7 amps at 5 VDC (10 watt) to keep your iPad powered and charging through all phases of flight. The package also includes a USB-C cable.

Keep it cool.

As they are being used, iPads generate heat that
can affect performance -- resulting in a high-temperature shut down when you might need it most! Pilots have found this out the hard way when using a temporary mounting solution like Velcro to attach their unit to the instrument panel. The smartPanel Mount was designed with cooling in
mind. Each mount has a built-in Fan Blower (14 or 28V) capable of supplying 4.6 cubic feet per minute of air and because it is powered by the aircraft you will not run out of battery. Each panel mounting tray features cooling channels to circulate Fan Blower air behind your iPad to keep it cool even under the heaviest of use.

Simple installation.

The smartPanel Mount is designed for easy
installation in your panel. Each durable molded ABS plastic unit is self-contained and mounts with only four screws. Our installation drawings give you the exact panel cutout details and screw positions in either PDF or AutoCAD DXF for precise cuts.

The included smartPower 150-301 Dual USB 2.7 amp
power supply mounts directly on the back of the panel mount, simplifying installation even further!

Both the Lightning Cable and Audio Cable mount directly in the specially designed ports in the iPad mount.

Mount in Automobiles, Boats, RVs, and Displays too!

Though the smartPanel Mount Package for iPad Air
4/5 Gen. was designed for use in aircraft, the durable construction and well-designed flush mount can be used easily for a wide variety of applications -- wherever there is a flat surface!

Automobile - - A great custom dashboard mount for
custom cars, auto restorations, or to incorporate into your own upgrade design to customize your car or truck. An easy way to add a clean and custom navigation display in any vehicle!

Marine / Boats - The thin profile flush mount
works well to create a custom bridge display in your boat, yacht, or watercraft for charts, weather, and navigation information. Mount in the wall of your cabin for a space-saving entertainment / communication / information system!

Recreational Vehicles (RVs) and Campers - Create a
custom mount in the wall of your trailer, RV, or mobile home to have a simple entertainment and communication system while saving space!

Displays / Office / Home Use - An easy-to-install
custom flush mount to add to trade show displays, retail kiosks, educational exhibits, home entertainment systems, and home management systems.
